Tascam Model12 Mixer/Interface/Recorder/Controller Tascam Model12 Mixer/Interface/Recorder/Controller Tascam Model12 Mixer/Interface/Recorder/Controller

Tascam Model12 Mixer/Interface/Recorder/Controller

8 395 kr
Finns i lager
3-4 dagars lev.tid
3-4 dagars lev.tid
3-4 dagars lev.tid

TASCAM Model 12
Tascam 10-Ch Analogue Mixer with 12-Track Digital Recorder

Integrated Production Suite for Music and Multimedia Creators

Tascam Model 12 – Integrated production suite for music and multimedia creators

Tascam Model 12 är en kompakt allt-i-ett-integrerad mixnings- och inspelningsmixer designad för musik- och multimediaskapare, låtskrivare och artister. Den består av en 10-ingångar, en 12-spårig version av  Tascams hyllade multi-track ljudinspelare, USB-interface, MIDI-anslutning, DAW-kontrollfunktioner och unik podcasting-funktion inklusive mix-minus och smartphone-ingång.

Den kompakta och prisvärda modellen 12 kombinerar känslan av ett analogt gränssnitt med det effektiva arbetsflödet och den orörda kvaliteten i samband med digital inspelning och produktion, och stöder din kreativa process från början till slut.


The Model 12’s intuitive internal 12-track recorder creates WAV files of up to24-bit/48 kHz audio quality directly to an SD card. Up to ten tracks can be played back simultaneously. Supporting metronome, punch-in/out, and overdubbing functions, the internal recorder also allows WAV files to be imported from another Tascam Model Series mixer like the Model 12, Model 16 or Model 24. And, of course, it is possible to export tracks in WAV file format which can then be imported directly into a DAW for further editing or production

Features at a glance

  • 10-channel mixer with built-in 12-track recorder and USB audio interface

Mixer features

  • Ten analogue inputs on six mono and two stereo channels
    • Eight mono mic inputs on XLR connectors with switchable phantom power (48 V)
    • Ultra-HDDA microphone preamps on inputs 1–6
    • Eight channels can be used with high-impedance instruments like electric guitars/basses
    • Ten balanced line inputs (six mono, two stereo)
    • Multi-purpose stereo channel for input from mobile devices via Bluetooth or TRRS smartphone connector (CH 9/10)
    • Inserts on input channels 1 and 2
    • Mix-minus function on smartphone mini-jack input
  • Two Aux outputs (monitor, effects) and two stereo outputs with independent master faders (Main, Sub)
  • Monitoring can be selected between PFL (pre-fader), AFL (after-fader) and SIP (solo-in-place)
  • Dedicated click output with tap tempo feature
  • One-knob compressor for all input channels
  • Three-band equalizer with sweepable mids for all input channels
  • Switchable low-cut filter (100 Hz) on each channel
  • Semi-parametric EQ with sweepable mid band for aux or main outputs
  • Built-in Bluetooth receiver for wireless playback
  • On-board effects processor
    • 16 effects types
    • Can be used on all input channels, aux busses, sub and main stereo bus
    • Can be turned on/off by an optional footswitch (Tascam RC-1F)
  • Compact 60-mm faders
  • 12-segment LED output level meters
  • XLR balanced outputs for main stereo bus
  • TRS balanced outputs for sub and aux outputs
  • Two headphones outputs with separate level controls

Recorder features

  • Tascam multi-track recording engine, uses SD cards as storage media (up to 512 GB)
  • Up to 12 tracks (10 input channels + stereo mix) can be recorded without the need for a computer
  • Recording/playback format: Linear PCM (WAV format, 44.1/48 kHz, 16/24 Bit)
  • Overdubbing, punch in/out recording
  • Multi-track playback for advanced live performance
  • Illuminated Play/Record/Stop buttons for better legibility in poorly lit environments

Audio interface features

  • USB audio interface for use with Windows (ASIO) and Mac (Core Audio) computers
  • Transfer to computer: 12 channels (all 10 inputs + stereo mix)
  • Transfer from computer: 10 channels, assignable to each channel input
  • Audio resolution 44.1/48 kHz, 16/24 bit
  • USB MIDI interface function
  • Simple DAW control support via HUI/MCU protocol emulation

Other features

  • MIDI input and output
  • Support for MIDI timecode (MTC) and MIDI clock output with song position pointer (SPP)
  • Simple and quick menu operation with multi-jog dial

New in firmware version 1.10

  • Vamp playback allows to automatically or manually repeat up to ten previously marked intervals per song
  • Metronome tempo can now also be changed with an audible click
  • Three volume options available for the accented note of the metronome click
  • New sound pattern with four bars for the count-in


VIDEO som beskriver hur du kan jobba med Model12

Windows 10 (October 2020, Version 20H2)
Windows 10 (November 2019 Update 1909)
Windows 10 (May 2019 Update 1903)
Windows 10 (April 2018 Update 1803)
Windows 8.1
Windows 7

macOS Catalina (10.15)
macOS Mojave (10.14)
macOS High Sierra (10.13)

iOS 14 / iPadOS 14
iOS 13 / iPadOS 13
iOS 12
iOS 11
